DIESEL ENGINE SYSTEM LG933

2

4110001031

发动机总成WP6G125E23（DHB06G0122）

ENGINE ASSEMBLY WP6G125E23（DHB06G0122）

Y

1

3

4015000026

垫圈GB93-12-65Mn

WASHER GB93-12-65Mn

N

12

4

4013000011

螺母GB6170-M12EpZn-8

NUT GB6170-M12 EpZn-8

N

8

5

4011000567

螺栓GB5785-M24*2*80EpZn-8.8

BOLT GB5785-M24*2*80-8.8

N

4

6

4013000157

螺母GB889.2-M24*2EpZn-8

NUT GB889.2-M24*2EpZn-8

N

4

7

3010900004

橡胶垫

RUBBER SPACER

Y

4

8

3010900003

接头螺钉

BOLT

Y

2

9

3010900007

垫圈

WASHER 12

Y

4

10

4011000092

螺栓GB5783-M12*50EpZn-8.8

BOLT GB5783-M12*50EpZn-8.8

N

4

11

29020008711

燃油箱总成

FUEL TANK ASSY

Y

1

12

4120000273

散热器总成LY-930S2

RADIATOR ASS'Y LY-930S2

Y

1

13

29010013641

停车操纵机构

PARKING BRAKE SYSTEM

N

1

14

2010900169

油门操纵机构

GOVERNOR CONTROL SYSTEM

N

1

15

4015000167

垫圈GB97.1-24EpZn-300HV

WASHER GB97.1-24EpZn-300HV

N

4

16

4015000168

垫圈GB97.1-12EpZn-300HV

WASHER GB97.1-12EpZn-300HV

N

4

17

4120000049

胶管JB8406-B16*2600

RUBBER TUBE JB8406-B16X2600

Y

1

18

4030000521

胶管JB8406-B16*1500

RUBBER TUBE JB8406-B16X1500

Y

1

19

4120000067

暖风机水阀LG12-NFJSF

VALVE-HEATER

Y

2

20

4017000024

环箍QC390-D26

CLAMP QC390-D26

N

4

21

29010008841

压力传感器接头

PRESSURE SENSOR

Y

1

22

29010015561

上盖板

UPPER COVER PLATE

Y

1

23

4011000081

螺栓GB5783-M10*20EpZn-8.8

BOLT GB5783-M10*20EpZn-8.8

N

10

24

4015000197

垫圈GB96.1-10EpZn-300HV

WASHER GB96.1-10EpZn-300HV

N

10

25

4013000033

GB6170-M8EpZn-8

NUT GB6170-M8EpZn-8

N

1
