IMPLEMENT HYDRAULIC SYSTEM CDM816D
|
Item |
Parts number |
Parts description |
Specification |
Qty |
Remarks |
|
|
1 |
LG818.07.01 |
转斗油缸 |
Turn fights oil cylinder |
1 |
||
|
2 |
GB/T5782 |
螺栓 |
Bolt |
M8×40-8.8 |
4 |
|
|
3 |
LG818.07-001 |
压块 |
Press block |
2 |
||
|
4 |
LG816.07.03 |
转斗缸大腔钢管 |
Tilt cylinder big chamber pipe |
1 |
||
|
5 |
JB999 |
管接头用铰接螺栓 |
Pipe connection link bolt |
M22×1.5×48 |
2 |
|
|
6 |
JB1002 |
垫圈 |
Washer |
22 |
4 |
|
|
7 |
16/16-II-L880 |
分配阀至转斗缸胶管 |
Pipe from distribution valve to tilt |
2 |
||
|
8 |
90H(H=106)-270°-90 H/25/28-II-L1000 |
铰接回油胶管 |
Articulated oil return hose |
1 |
||
|
9 |
90H-90° -90H/19/18-II-L1000 |
铰接进油胶管 |
Articulated oil inlet hose |
1 |
||
|
10 |
LG816.07.17 |
优先阀 |
Priority valve |
1 |
YXL-F160L |
|
|
11 |
GB/T5782 |
螺栓 |
Bolt |
M8×80-8.8 |
2 |
|
|
12 |
GB/T93 |
垫圈 |
Washer |
8 |
14 |
|
|
13 |
LG816.07.18 |
工作泵 |
Implement pump |
1 |
CBGj2050 |
|
|
14 |
LG816.07-001 |
压板 |
Press plate |
1 |
306001D |
|
|
15 |
GB/T3452.1 |
O 形圈 |
O-ring |
25×3.55 |
1 |
|
|
16 |
GB/T5783 |
螺栓 |
Bolt |
M8×40-8.8 |
4 |
|
|
17 |
GB/T5783 |
螺栓 |
Bolt |
M12×35-8.8 |
4 |
|
|
18 |
GB/T93 |
垫圈 |
Washer |
12 |
8 |
|
|
19 |
GB/T97.1 |
垫圈 |
Washer |
12 |
6 |
|
|
20 |
90F-H/19/18-II-L730 |
泵至优先阀胶管 |
Hose from pump to Priority valve |
1 |
||
|
21 |
LG816.07-002 |
接头体 |
Dapter |
2 |
||
|
22 |
JB1002 |
垫圈 |
Washer |
27 |
2 |
|
|
23 |
GB3733.2-83 |
接头体 |
Dapter |
G8 |
1 |
|
|
24 |
JB1002 |
垫圈 |
Washer |
12 |
1 |
|
|
25 |
90H-H-8/8-I-L600 |
优先阀回油胶管 |
Priority valve oil return hose |
1 |
||
|
26 |
13/14-II-L270 |
动臂缸小腔胶管 |
Lift cylinder small chamber hose |
2 |
||
|
27 |
20411-20GB/20491- 20GB*2W08*950+R S |
动臂油缸胶管 |
Lift cylinder hose |
4 |
||
|
28 |
LG816.07.04 |
左侧动臂缸固定管座 |
Fixed socket of left side lift cylinder |
1 |
||
|
29 |
LG816.07.05 |
右侧动臂缸固定管座 |
Fixed socket of right side lift cylinder |
1 |
||
|
30 |
LG816.07-003 |
压板 |
Press plate |
10 |
7 |
|
|
31 |
GB/T5783 |
螺栓 |
Bolt |
M8×30-8.8 |
4 |
|
|
32 |
GB/T93 |
垫圈 |
Washer |
8 |
4 |
|
|
33 |
GB/T5783 |
螺栓 |
Bolt |
M8-8 |
4 |
|
|
34 |
GB/T97.1 |
垫圈 |
Washer |
2 |
||
|
35 |
GB/T6170 |
螺母 |
Nut |
1 |
||
|
36 |
13/14-II-L300 |
动臂缸大腔胶管 |
Lift cylinder big chamber pipe |
1 |
||
|
37 |
LG816.07.16 |
右侧油缸小腔钢管 |
Small chamber pipe of right side cylinder |
2 |
||
|
38 |
LG816.07.07 |
右侧油缸大腔钢管 |
Big chamber pipe of right side cylinder |
2 |
||
|
39 |
13/14-II-L470 |
分流胶管 |
Distributing hose |
1 |
||
|
40 |
LG818.07.02 |
动臂油缸 |
Arm oil cylinder |
1 |
||
|
41 |
LG816.07.08 |
转斗油缸小腔钢管 |
Tilt cylinder small chamber pipe |
1 |
||
|
42 |
LG816.07.14 |
分配阀至转斗小腔钢管 |
Small chamber pipe from distribution valve to tilt |
M12×55-8.8 |
4 |
|
|
43 |
LG816.07.19 |
多路换向阀 |
Implement valve |
M12-8 |
4 |
|
|
44 |
GB/T5782 |
螺栓 |
Bolt |
10 |
4 |
|
|
45 |
GB/T6170 |
螺母 |
Nut |
M8×30-8.8 |
6 |
|
|
46 |
LG816.07-004 |
分配阀到动臂缸、转斗缸的 A、 B 口接头 |
A,B port connection from distribution valve to lift cylinder ,tilt cylinder |
4 |
||
|
47 |
GB3452.1-92 |
O 形圈 |
O-ring |
26.5×2.65 |
6 |
|
|
48 |
LG816.07.15 |
分配阀至转斗大腔钢管 |
Big chamber pipe from distribution valve to tilt |
1 |
||
|
49 |
16/16-II-L800 |
分配阀至动臂缸胶管 |
Hose from distribution valve to lift cylinder |
2 |
||
|
50 |
LG818.07.09 |
左侧油缸大腔钢管 |
Big chamber pipe of left side cylinder |
1 |
||
|
51 |
LG818.07.10 |
左侧油缸小腔钢管 |
Small chamber pipe of left side cylinder |
1 |
||
|
52 |
LG816.07－005 |
接头体 |
Adapter |
1 |
||
|
53 |
LG816.07－006 |
分配阀 P 口接头 |
P port connection of distribution valve |
1 |
||
|
54 |
LG853.07－002 |
前（后）车架进油过渡接头压板 |
Front/rear frame oil inlet transmit joint press plate |
1 |
||
|
55 |
GB/T5783 |
螺栓 |
Bolt |
M10×40-8.8 |
1 |
|
|
56 |
LG816.07.11 |
回油管座 |
Oil return socket |
1 |
||
|
57 |
JB/T8870 |
喉箍 |
Hoop |
32~44 |
2 |
|
|
58 |
ф25X2-170mm |
回油箱夹布胶管 |
Oil return tank hose |
1 |
||
|
59 |
LG816.07.13 |
回油钢管 |
Oil return pipe |
1 |
||
|
60 |
90H-270°-90H/2 5/28-II-L95 |
吸油胶管 |
Oil suction hose |
1 |
||
|
61 |
LG816.07.12 |
吸油钢管 |
Oil suction pipe |
1 |
||
|
62 |
GB/T3452.1 |
O 形圈 |
O-ring |
28.0×2.65 |
1 |
|
