DIESEL ENGINE SYSTEM CDM816D

Item

Parts number

Parts description

Specification

Qty

Remarks

1

LG816B.01III.01

油门软轴

THROTTLE FLEXIBLE SHAFT

1

L1600

2

CDM816.01.01

柴油机总成

ENGINE ASSEMBLY

1

3

LG818.01I-001

水箱进水管

RADIATOR WATER INLET PIPE

1

4

LG818.01I.04

散热器总成

RADIATOR

1

5

GB/T5783

螺栓

BOLT

M12×50-8.8

4

6

GB/T97.1

垫圈

WASHER

12

4

7

LG816.01-002

水箱胶垫

RADIATOR RUBBER PAD

2

水箱自带 Selecting radiator

8

JB/T8870

喉箍

HOOP

Φ40-60

4

9

LG818.01I-003

水箱出水管

RADIATOR WATER OUTLET PIPE

1

10

QX518.26.04

E 型减震器

E-TYPE SHOCK ABSORBER

4

E220

11

LG816B.01Ⅲ.05

发动机右后支架焊合

ENGINE RIGHT REAR BRACKET

1

12

LG816B.01Ⅲ.06

发动机左后支架焊合

ENGINE LEFT REAR BRACKET

1

13

GB/T5783

螺栓

BOLT

M12×35-8.8

16

14

GB/T93

垫圈

WASHER

12

20

15

LG816B.01Ⅲ.07

发动机右前支架焊合

ENGINE RIGHT FRONT BRACKET

1

16

LG816B.01III.08

发动机左前支架

ENGINE LEFT FRONT BRACKET

1

17

GB/T5783

螺栓

BOLT

M22×55-8.8

4

18

GB/T93

垫圈

WASHER

22

4

19

GB/T97.1

垫圈

WASHER

22

4

20

GB/T5783

螺栓

BOLT

M14×35-8.8

4

21

GB/T6170

螺母

NUT

M14-8

8

22

GB/T97.1

垫圈

WASHER

14

8

23

GB/T93

垫圈

WASHER

14

8

24

GB/T5783

螺栓

BOLT

M14×50-8.8

4

25

LG853.01.06.02

油门踏板总成

THROTTLE PEDAL ASSEMBLY

1

26

GB/T5783

螺栓

BOLT

M6×16-8.8

5

27

GB/T93

垫圈

WASHER

6

5

28

LG810.01-008

固定板

FIXING BOARD

1

29

GB/T96.1

垫圈

WASHER

6

2

30

GB/T6170

螺母

NUT

M6-8

2

31

JB/T966

铜垫

COPPER WASHER

14

2

32

401007(401014D)

接头体

ADAPTER

1

401007

33

JB/ZQ4450

螺塞

MAGNETIC PLUG

M14×1.5

1
