FRAME SYSTEM CDM816D

Item

Parts number

Parts description

Specification

Qty

Remarks

1

LG816.10-001

优先阀固定板

Priority valve securing board

1

2

GB/T93

垫圈

Washer

8

2

3

GB/T5783

螺栓

Bolt

M8×20-8.8

2

4

LG818.10.01

前车架焊合

Front frame weldment

1

5

LG818D.10.02

后车架焊合

Rear frame weldment

1

6

LG816.10.05

转向缸销

Steering cylinder pin weldment

2

7

LG816.10.06

钢管焊合

Pipe weldment

1

8

LG853.05.02-012

通油螺栓

Oil bolt

2

9

LG853.10.06-005

垫圈

Washer

10

4

10

LG816.10.08

摆动架焊合

Oscillating suspension weldment

1

11

LG816.10-002

摆动架轴套

Oscillating suspension shaft sleeve

2

12

LG816.10.09

摆动架销焊合

Oscillating suspension pin weldment

2

13

LG816.10.10

上铰接销轴焊合

Upper hitch pin

1

14

GB/T13871.1

密封圈

Seal

FW40×62×8

2

15

GB/T5783

螺栓

Bolt

M12×40-8.8

12

16

LG816.10-003

上轴承盖

Upper bearing cover

1

17

LG816.10-004

上轴承座

Upper bearing cover

1

18

GB/T9163

关节轴承

Joint bearing ge40es

GE40ES

2

19

LG816.10-005

下铰接销轴

Lower bearing pin

1

20

LG816.10-006

下铰接上套

Lower hitch pin upper bush

1

21

GB/T13871.1

密封圈

Seal ring

FW50×68×8

2

22

LG816.10-007

下轴承盖

Lower bearing cover

1

23

LG816.10-008

下轴承座

Lower bearing seat

1

24

LG816.10-009

下铰接下套

Lower hitch pin lower bush

1

25

LG816.10-010

调整垫片

Spacer

1

26

LG816.10-011

垫板

Spacer

1

27

GB/T9459

螺母

Nut

M20×2-5

1

28

GB/T91

开口销

Cotter pin

5×50

1

29

GB/T5783

螺栓

Bolt

M12×25-8.8

10

30

GB/T97.1

垫圈

Washer

12

10

31

GB/T93

垫圈

Washer

12

22

32

LG816.10.11

动臂缸销焊合

Lift cylinder pin weldment

2

33

LG816.10.12

动臂上销焊合

Lift arm upper pin weldment

2

34

LG816.10.13

翻斗缸销焊合

Tilt arm pin weldment

1

35

JB/T7940.1

油杯

Oil cup

M10×1

11

36

LG816.10-012

摆动架铜垫

Oscillating suspension copper pad

2

37

LG816.10-013

滤油器固定板

Fixing board of filter

1

38

GB/T5783

螺栓

Bolt

M10×20-8.8

9

39

GB/T93

垫圈

Washer

10

9

40

GB/T5782

螺栓

Bolt

M20×100-8.8

1

41

GB/T93

垫圈

Washer

20

1

42

GB/T6170

螺母

Nut

M20-8

1

43

LG818.10-014

盖板

Cover board

1

44

GB/T97.1

垫圈

Washer

10

9

45

GB/T97.1

垫圈

Washer

8

2
