FRONT、REAR AXLE ASSEMBLY LG918

Key Part No.   Description Spare parts Y/N Oty
1 4120001827 LG918 DISC BRAKE-LG918 Y 4

2

4011000698

螺栓GB5786-M16*1.5*55EpZn-8.8

BOLT GB5786-M16*1.5*55EpZn-8.8

N

16

3

29070009511

垫圈

WASHER

N

16

4

29070010011

前桥壳总成

FRONT AXLE HOUSING

Y

2

5

4011000568

螺栓GB5786-M12*1.25*40EpZn-10.9

BOLT GB5786-M12*1.25*40EpZn-10.9

N

24

6

4015000026

垫圈GB93-12-65Mn

WASHER GB93-12-65Mn

N

24

7

29070010021

前主传动

FRONT AXLE MAIN DRIVE

Y

1

8

29070008051

盖帽

HOOD

Y

2

9

4090000097

钢球GB308-6-GCr15

STEEL BALL GB308-6-GCr15

Y

2

10

29070008021

透气帽体

AERATION CAP BODY

Y

2

11

3050900003

轮辋螺母

RIM NUT

Y

32

12

29070010031

轮边减速器

FINAL DRIVE

N

4

13

29090008001

后主传动

REAR AXLE MAIN DRIVE

Y

1
