STEERING HYDRAULIC SYSTEM CDM816D

Item

Parts number

Parts description

Specification

Qty

Remarks

1

LG816.06.03A

转向油缸

Steering cylinder

Φ80/Φ45

1



2

20491-20GB*2W08*1300/270°

胶管总成

Hose assembly



1



3

20471-20GB/20491-20GB*2W08*90

0/290°

胶管总成

Hose assembly



1



4

20491-20GB*2W08*610/225°

胶管总成

Hose assembly



1



5

LG816.06-001

优先阀 CF 口接头

Priority valve port cf connector



1



6

JB/T966

垫圈

Washer

22

1



7

90H-270°-90H-13/14II-L580

转向器回油胶管总成

Steering gear oil return hose assembly



1



8

20491-14*1W05*600

胶管总成

Hose assembly



1



9

GB3733.2

接头体 G8

Connector g8



2



10

JB/T966

垫圈

Washer

12

2



11

LG816.06-003

转向器接头

Steering gear connector



4



12

JB/T966

垫圈

Washer

20

4



13

LG816.06.02.02

全液压转向机(带阀块)

Hydraulic steering gear with

valve block(select implement)



1



14

GB/T5783

螺栓

Bolt

M10×30-8.8

4



15

GB/T93

垫圈

Washer

10

4



16

GB/T97.1

垫圈

Washer

10

4



17

LG816.06-004

石棉垫

Asbestos gasket



1
