TORQUE CONVERTER SYSTEM CDM816D

Item

Parts number

Parts description

Specification

Qty

Remarks

1

GB/T93

垫圈

WASHER

10

12



2

GB/T5783

螺栓

BOLT

M10×30-8.8

12



3

LG816.02.01

液力变矩器总成

TORQUE CONVERTER ASSEMBLY



1

YJ280-1C(4D)

4

LG816.02.02

双变液压总成

TORQUE CONVERTER AND TRANSMISSION HYDRAULIC ASSEMBLY



1



5

LG816.02Ⅱ.03

上传动轴总成

UPPER DRIVE SHAFT ASSEMBLY



1



6

GB/T5786

螺栓

BOLT

M12×1.5×35-8.8

4



7

GB/T889.2

螺母

NUT

M12×1.5-8

8



8

GB/T5786

螺栓

BOLT

M12×1.5×40-8.8

4



9

GB/T5783

螺栓

BOLT

M12×25-8.8

9



10

GB/T93

垫圈

WASHER

12

9
