Work Device Hydraulic Container Lift Oil hydraulic pipe YTO–ZL50D-II

No.

Parts Name

Drawing No.

Qty.

Assembly No.

1

Bearing

Piston rod

Retaining ring 140

O ring 160×3.1

Retaining ring

Steel retaining ring

O ring 140×3.1

U sealing ring

Leading cover

Sealing ring d80

O ring 160×5.7

Support ring 160×3×15

O ring 85×3.1

Screw M12×45

Piston

Washer 135

Sealing ring 160

Container body

GB 3945-83

1

ZL50TY.13.00

2

507204D

1

ZL50TY.13.00

3

GB 894.1-86

1

ZL50TY.13.00

4

GB 1235-76

1

ZL50TY.13.00

5

507201D

1

ZL50TY.13.00

6

507202D

1

ZL50TY.13.00

7

GB 1235-76

1

ZL50TY.13.00

8

T20

1

ZL50TY.13.00

9

507203E

1

ZL50TY.13.00

10

YZJ-0800

1

ZL50TY.13.00

11

GB 1235-76

1

ZL50TY.13.00

12

ZGP160-02

2

ZL50TY.13.00

13

GB 1235-76

1

ZL50TY.13.00

14

GB 79-85

1

ZL50TY.13.00

15

507209D

1

ZL50TY.13.00

16

ZGP160-03

1

ZL50TY.13.00

17

ZGP160-01

1

ZL50TY.13.00

18

507205-08

1

ZL50TY.13.00
